Description
Dental Suction Unit Machine Support 1-4 PCS Dental Chair,CE Approved
Features
1.Efficient separation,Compact structure,Low use-cost.
Let air and liquid separate in the small room. Separation system and vacuum pump is connected in the same central driving sharft , don’t need instal separation system in the dental unit,don’t need any other traditional system’s working cost—as water pump.
2.Strong Power.
Adopt width voltage and double frequence,motor with protection leve IP55(insulation grade F) as drive,accomplish turbine circulation suction power,lower noise, higher pressure,larger flowing. Offer the constant suction power for treatment.
3.Regulation and cooling.
Built-in auxiliary air valve,not only regulate suction power of system,but also ensure inside cooling of pump.
4.Corrosion resistance.
Separation system adopt high grade engineering plastics,corrosion resistance,long use-life time.
5.Two stage separation system.
Innovative two stage separation system,have higher foam tolerance,ensure out-air without any water,avoid pump damage.
Specifications
| Number Of Dental Chair | 1-2 PCS | 3-4PCS |
| Voltage | AC 110V/60Hz or 220V/50Hz±10% | AC 110V/60Hz or 220V/50Hz±10% |
| Power (W) | 50Hz 800W/ 60Hz 850W | 50Hz 1200W/ 60Hz 1400W |
| Air flow (L/min) | ≧500 | ≧950 |
| Max. Negative Pressure(Kpa) | ≦-15 | ≦-18 |
| Noise (dB) | ≤60 | ≤60 |
| Fuse (A) | 50Hz 4.8A/ 60Hz 5.2A | 50Hz 7.3A/ 60Hz 8.3A |
| Packing size (CM) | 53*37*65 | 55*39*72 |
| N.W./G.W.(KG) | 26 / 37 | 34.5 / 44 |
Pipeline
